Air Insulated Load Break Switches

Air Insulated Load Break Switches

0.00

Insulect manufacture side-break and vertical-break air insulated load break switches. Within this range we produce several versions and customise to suit individual network requirements.

Air Break Switches are widely installed throughout distribution networks for use as both isolating and switching points.

  • 12/24kV and 36kV Voltage ratings

  • 630 and 1250 amps load current ratings

Add To Cart



AIR BREAK SWITCH SPECIFICATION

Insulect Air Break Switches (ABS) are designed, assembled and tested in Australia.

Our range is widely installed throughout distribution networks for isolation or switching applications.

AIR BREAK SWITCHES
BROCHURE





Voltage Range

12, 24, 36kV


Configuration

Vertical or side break

power pole.png

Installation

Horizontal or vertical (pole top or mid pole)


Designed and Tested

to AS 62271.102 / IEC 62271.102





TYPICAL CONFIGURATIONS FOR AIR BREAK SWITCHES


Pole Top, Side Break air insulated switch with hook stick actuator.


Pole Top, Side Break air insulated switch with manual operating handle.

Mid-Pole-Side-Break-Switch-with-manual-operating-handle-and-associated-Earth-Switch.jpg

Mid Pole, Side Break air insulated switch with manual operating handle and associated Earth Switch.


Mid Pole, Vertical Break air insulated switch with manual operating handle.




AIR BREAK SWITCH FEATURES

MODULAR DESIGN
We readily provide custom design changes to suit individual customer requirements, as well as modular or unitised factory assembly for more rapid installation.

INSULATORS
Choose to specify Porcelain, Silicon or Cycloaliphatic insulators.

MANUAL OR MOTORISED CONTROL
Available with conventional operating rod and handle, with patented hook stick actuator. Able to be fitted with motorised operation as well as remote control facilities.

OPTIONS
Associated earthing switch available.
Load interrupter to break up to 630 A.
