Qualitrol 032-042-045 Large Oil Level Indicator

Qualitrol 032-042-045 Large Oil Level Indicator

0.00

The 032-042-045 Series oil level indicators from Qualitrol provide continuous indication of the liquid level inside of a transformer’s main tank, conservator tank or load tap changer compartment.

Models are available with gear driven or lever driven float mechanisms. The gear driven mechanism provides amplified pointer movement relative to corresponding float travel. Lever driven gauges offers slimmer profile for tight spaces within a transformer. Integrated switches allow for limit and alarm control functions.

Add To Cart

Better transformer protection with accurate oil level monitoring and alarm and limit functions

Low level and high level alarm control is made possible with up to 3 integrated switches for 032, 042 and 045 models and up to 4 switches for the AKM 44712 and 34725 models.

The gear driven mechanism provides amplified pointer movement relative to the corresponding float movement for enhanced clarity of visual display. Models with analogue output (0-1 mA or 4-20 mA) allow for continuous remote monitoring of oil level.

Rugged design and corrosion resistant materials provide long, trouble free life

The die-cast aluminium housing is coated with a thermosetting powder coat finish. Stainless steel and corrosion resistant parts protect gauge against harsh environmental conditions. Optional UV resistant polycarbonate lens resists yellowing with age.

The 045 models are designed for hazardous locations and are UL listed for class 1 div 2.

Numerous options provide customised solutions for your application

Switching can be supplied for various liquid levels. Both industry-standard and custom engineered dial markings are available. A wide variety of electrical connections are available including quick connects, Military style, ANSI, conduit-ready and terminal box styles.


Qualitrol 032-042-045 Series Transformer Oil Level Indicator.png

Qualitrol 032-042-045 OLI Brochure

Oil Level Indicators



Features of the 032-042-045 Series Transformer Oil Level Indicator


  • 6 inch (150 mm) dial face with lever (radial) or heavy duty gear driven float arm for use in various tank geometry

  • 032/042 feature a field replaceable case (dial) can be exchanged without lowering oil level or compromising tank seal

  • Up to 2 adjustable SPDT switches (032/042 features rotatable lens for switch testing)

  • Magnetically coupled for leak free operation

  • Low level and high level alarm control is made possible with up to 3 integrated switches for 032, 042 and 045 models and up to 4 switches for 44712 and 34725 models

  • Die-cast Aluminum housing is coated with a thermosetting powder coat finish

  • Stainless steel and corrosion resistant parts protect gauge against harsh environmental conditions

  • 045 models are designed for hazardous locations and are UL listed for class 1 div 2




Options: 032-042-045 Series Oil Level Indicator


  • Optional UV resistant polycarbonate lens resists yellowing with age

  • A wide variety of electrical connections are available including quick connects, Military style, ANSI, conduit-ready and terminal box styles

  • Resistive (potentiometer) or 4-20mA electronic output for remote indication and SCADA system integration

  • Universal replacement case for field replacement (032/042/045)

  • Float travel ranges from min to max markings for various tank configurations

  • Tank connection (flange) style, materials, dial style and dial layout

  • Electrical connection types, cable size, lengths and wire colours


For highly visible indication of oil or liquid level with switches (contacts) for control or alarm functions.
— Qualitrol
